We are a leading manufacturer specializing in high-density multilayer printed circuit boards and specialty boards. With certifications including UL, ISO9001:2015, ISO14001:2015, CQC, IATF16949:2016, and "National Military Standard," we provide top-quality products and services. Our extensive product range includes multilayer boards, impedance boards, high-frequency boards, high TG thick copper foil boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, specialty boards, and customized solutions.
Driven by technological innovation, our products are widely used in industries such as communication equipment, industrial control, automotive electronics, energy and power, medical devices, IoT, research institutions, aerospace, and defense. With over 19 years of experience, we have served over 1,000 technology innovation-oriented enterprises with rapid prototyping and mass production services. We are committed to delivering cutting-edge solutions and exceeding customer expectations in the dynamic electronics industry.
| Rigid PCB Manufacturing Capability | |||
|---|---|---|---|
| Category | Specification Detail | Volume Production | Sample Processing |
| Layer Count | - | 1-68L | 64 Layer |
| Max Thickness | - | 10mm (394mil) | 14mm (551mil) |
| Min Line Width/Space | Inner Layer | 2.2mil / 2.2mil | 2.0mil / 2.0mil |
| Outer Layer | 2.5mil / 2.5mil | 2.2mil / 2.2mil | |
| Alignment Capability | Alignment with Core Board | ±25um | ±20um |
| Inner Layer Alignment | ±5mil | ±4mil | |
| Max Copper | - | 6oz | 30oz |
| Holes Size | Mechanical Drilling | ≥0.15mm (6mil) | ≥0.1mm (4mil) |
| Laser Drilling | 0.1mm (4mil) | 0.050mm (2mil) | |
| Max Size | Unit Size | 850mm X 570mm | 1000mm X 600mm |
| Panel Size | 1250mm X 570mm | 1320mm X 600mm | |
| Aspect Ratio | Unit Size | 20:1 | 28:1 |
| Panel Size | 25:1 | 35:1 | |
| Material | Lead-Free / Halogen-Free | EM827, 370HR, S1000-2, IT180A, EM825, IT158, S1000 / S1155, R1566W, EM285, TU862HF | |
| High-Speed PCB Material | Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, N4000-13 Series, MW4000, MW2000, TU933 | ||
| High-Frequency PCB Material | Ro3003, Ro3006, Ro4350B, Ro4360G2, Ro4835, CLTE, Genclad, RF35, FastRise27 | ||
| Others | Polyimide, Tk, LCP, BT, C-ply, Fradflex, Omega, ZBC2000 | ||
| Surface Finished | - | HAL, HAL-LF, ENIG, Immersion Tin, OSP, Immersion Silver, Gold Finger, Hard/Soft Gold Plating | |
| Special Technology | - | Blind & Buried holes, Via in pad, Semi-plating holes, Counterbore, Step mounting holes, Drill Mixed RF PCB, Busbar PCB | |
As PCBs are custom products, returns are not supported. For quality issues, please contact support for a refund or replacement. We do not bear any losses or costs beyond the product value. Delays in delivery due to force majeure factors (e.g., power outages or water supply interruptions) will not be compensated.
For specific requirements or special instructions, please communicate directly for confirmation. Do not leave messages in unattended forms, as we will not be responsible for missed messages. Please confirm the process, quantity, and layers before and after payment. Refunds are not eligible after production or shipment. If purchasing personnel lack technical knowledge, please confirm details with your engineer.
Orders placed before 17:00 are considered as placed on the same day; orders placed after 17:00 are considered as placed the next day. "24-hour delivery" refers to one working day, not 24 consecutive hours. Delivery times provided do not include Sundays or holidays.
Standard: Green solder mask, white silkscreen, 1.6mm board thickness, HASL, 1oz copper thickness, vias with solder mask, line width/spacing 0.2mm, vias above 0.3mm. Gerber formats are processed according to provided files. Quotations are based on standard processes; please inform us of any special requirements for a customized quotation.
| Layer | Sample Shortest Lead Time | Sample Standard Lead Time | Mass Production Lead Time |
|---|---|---|---|
| 2 Layers | 24 h | 3 days | 6-7 days |
| 4 Layers | 36 h | 5 days | 8-10 days |
| 6 Layers | 48 h | 5 days | 8-12 days |
| 8 Layers | 72 h | 5 days | 9-12 days |
| 10 Layers | 4 days | 7 days | 14 days |
| 12 Layers | 4 days | 7 days | 16 days |
| 14 Layers | 5 days | 8 days | 16 days |
| 16 Layers | 5 days | 9 days | 18 days |
| 18 Layers | 7 days | 10 days | 18 days |
| 20 Layers and above | To be negotiated | To be negotiated | To be negotiated |
